Carbon Steel Water Well Drilling Tools Sub Adapters Drill Bit Connector
Application
JCDRILL can make any and all types of drill string subs. All subs made are API inspected and certified, or they may be new with mill certs. Subs are shorter components of the the drill string, averaging only four feet in length. Most subs are used as an adapter between two different connection types in the same drill string. Often times the connection on drill pipe will differ from that of the bottom hole assembly (drill collars and heavy-weight) and a crossover sub must be used to adapt the two different connections. Another common type of sub is a bit sub. A bit sub is one that is used just above the bit and serves as a crossover between the drill collar connections and the bit connection, and it also houses the float valve. The float valve is basically a one-way fluid valve that allows drilling fluids to pass out of the drill string and into the bit but does not allow those fluids to back-flow into the drill string.
Available Adapter Configurations:
- Box x Pin
- Pin x Pin
- Box x Box
- Pin x Blank
- Box x Blank
Flats depth on subs may be measured in two different ways. The first, and most common, is by the depth
of the flat from the diameter of the sub (1), how much material is removed. The second method of measurement
is to measure the distance between the flat surface to flat surface (2), or the opening of the pipe-handling tool.
If the flat has a taper, please give us the length at the top and again at the bottom of the flat.
Specification
| Female A | Male B | Diameter A | Diameter B | Length |
| 2 3/8API Reg | 2 3/8API Reg | 77 | 77 | 140 |
| 2 3/8API Reg | 2 3/8API Reg | 90 | 90 | 140 |
| 2 3/8API Reg | 2 3/8API Reg | 102 | 102 | 130 |
| 2 3/8API Reg | 2 3/8API Reg | 90 | 90 | 144 |
| 2 3/8API Reg | 2 3/8API IF | 95 | 95 | 130 |
| 2 3/8API Reg | 2 7/8API Reg | 90 | 102 | 120 |
| 2 3/8API IF | 3 1/2API Reg | 90 | 90 | 164 |
| 2 7/8API Reg | 2 3/8API Reg | 90 | 90 | 154 |
| 2 7/8API Reg | 2 3/8API Reg | 90 | 115 | 120 |
| 3 1/2API Reg | 3 1/2API Reg | 115 | 115 | 219 |
| 3 1/2API Reg | 2 3/8API IF | 115 | 115 | 160 |
| 3 1/2API Reg | 2 7/8API Reg | 115 | 115 | 160 |
| 3 1/2API Reg | 2 7/8API IF | 115 | 115 | 160 |
| 3 1/2API Reg | 3 1/2API Reg | 115 | 115 | 160 |
| 3 1/2API Reg | 4 1/2API Reg | 146 | 146 | 132 |
| 4 1/2API Reg | 3 1/2API Reg | 146 | 115 | 235 |
| F48×10 | F42×10 | 59 | 59 | 203 |
| F48×10 | F48×10 | 59 | 59 | 203 |
| F48×10 | 2"API Reg | 59 | 59 | 203 |
| Female A | Male B | Diameter A | Diameter B | Length |
| 2 3/8API Reg | 2 3/8API Reg | 77 | 77 | 200 |
| 2 3/8API Reg | 2 3/8API Reg | 90 | 90 | 200 |
| 2 3/8API Reg | 2 7/8API Reg | 90 | 90 | 225 |
| 2 3/8API Reg | 3 1/2API Reg | 115 | 115 | 210 |
| Female A | Male B | Diameter A | Diameter B | Length |
| 2 3/8API Reg | 2 3/8API Reg | 90 | 90 | 70 |
| 2 3/8API Reg | 3 1/2API Reg | 90 | 115 | 97 |
| 3 1/2API Reg | 3 1/2API Reg | 115 | 115 | 90 |
Packing& Delivery
FAQ
1. Shipping time for an order
We have many stock. As usual, we can delivery the goods as soon as we get the full payment.
2. Quality Control
Strict inspection and testing for every order before shipping out .
3.How can we trust your company?
We support Alibaba trade insurance. Protect products quality, shipment on time and your covered amount.
4. After Sales Service
Free replacement will provide once the failure confirmed caused by our product quality.
